Print Head

Drop On Demand Piezoelectric Head

No. of print head

1-4

Productivity

DX5(1H)    DX5(2H)    XP600(2H)    XP600(4H)

Production

32 sqm/h    65 sqm/h    23 sqm/h    46 sqm/h

Quality

22sqm/h    44 sqm/h    16 sqm/h    32 sqm/h

Fine Art

17 sqm/h    34 sqm/h    11 sqm/h    22 sqm/h

Resolution & Software

Resolutions

2880dpi Max.

Software

Standard (Maintop/photoprint) ; Other RIPs available as optional

Media

Media Width

Maximum 1622mm

Roll diamention & Weight

Max. 210mm, 40KG

Print Width

1600mm in one roll

Feeding&Taking-up System

Auto-Feeding system and take-up system

Inks

Type

Eco Solvent / Water Base

Ink Supply System

1.5L Large Bulk System with automatic supply system

Colors

Standard CMYK; Others Configuration Optional

Ink curing system

Integrated Tri-Heating System, Extend infrared heating and cooling system

Dimensions & Weight

Machine(L*W*H)

X2(2722x615x1223mm)    X2S(2708x960x 1390mm)

Package(L*W*H)

X2(2860x760x650mm)    X2S(2800x770x745mm)

Operation Requirements

Connectivity

Hi-Speed USB 3.0

Power

Single Phase, 220VAC±10%, 50/60Hz; 600W(Machine),900W(Heater)

Environment

Temp. 15~30°C; RH 40~60%;

Warranty

Warranty

1 Year Warranty Standard, More information please consult our local dealer
